Automatic stretch wrapping machine with rotating ring GENESIS THUNDER [CLONE]

  Description:

     Born to set higher standards

  • HI-RESISTANCE MONOBLOCK ALUMINIUM RING
  • SERVO CONTROLLED DIRECT-DRIVE PRE-STRETCH MOTORS
  • HYGIENIC & ERGONOMIC DESIGN
  • NOISELESS OPERATION WITH EXTREMELY REDUCED MAINTENANCE
  • ENGINEERED TO REDUCE MAINTENANCE & INTERVENTIONS
  • AUTOMATIC DYNAMIC PARACHUTE
  • MAXIMUM FLEXIBILITY WITH ALL THE PALLET SIZES

Types of wrapping machines:

Înfoliere automată paleți - Genesis Thunder

Înfoliere automată paleți - Genesis Thunder

Înfoliere automată paleți - Genesis Thunder

  GENESIS THUNDER HS       sigle head

     GENESIS THUNDER 2         double head

GENESIS THUNDER HS/2  double head high-speed

Key features:

  Genesis THUNDER
Min-max pallet dimensions (mm) 400x600 - 1270x1270
Max pallet height (mm) 500 - 2000; 1000 - 2000 T.I*
Output capacity (paleti/h)  more than 200 pallet / h -  T.I.*
Pre-stretch carriage BGS; BVS
Power supply voltage (V) 400 -415 ± 5%
Power supply frequency (Hz) 50
Air pressure (bar) 6 ± 1
Air consumption (Nl/min) 250; 350 T.I.
Reel height (mm) 500
Max reel diameter (mm) 250
Film thickness workable (µm) 17 - 30
TOP Film thickness (µm) 40 - 100

* T.I. - With top sheet applicator.

  Options:

Pre-stretch carriages:

Înfoliere automată paleți, preîntindere BGS Înfoliere automată paleți, preîntindere BVS
BGS BVS
  • BGS - Servo controlled single motor pre-stretch carriage with external direct-drive motorization.
    The carriage, as is traditional for Robopac Systems, works without sliding contacts, eliminating all failures caused by this technology, ensuring greater safety levels and the possibility of use in all environments.
  • BVS - Servo controlled two motors pre-stretch carriage with external direct-drive motorization.
    The carriage, as is traditional for Robopac Systems, works without sliding contacts, eliminating all failures caused by this technology, ensuring greater safety levels and the possibility of use in all environments.

Clamps cut and seal the film at the end of the wrapping:

Înfoliere automată paleți, sudare folie Înfoliere paleți, dispozitiv lipire folie
Integrated system with cutting and welding Clamp with wrapping film tail insertion

Others:

Înfoliere automată paleți, placă presoare Înfoliere paleți accesorii, lift paleți Înfoliere automată paleți, capac folie
Pressure platen Pallet lifter Top cover
 Înfoliere automată paleți, roping Înfoliere paleți, aplicare colțare Înfoliere paleți, schimbare rolă
Roping Corner applicator Arc reel-change
Video:

Genesis Thunder:

 Genesis Thunder HS/2:



GENESIS THUNDER (4,059 Kb) [Download]

AUTOMATIC STRETCH WRAPPERS (8,150 Kb) [Download]

For this equipment ask the Packaging department for information:

Hrimiuc Iulian,
Packaging Manager
+40 753 010 742

iulian.hrimiuc@mach.ro
